32'*52'*18'
High Strength bolt M20 Grade: Class 10.9S
(ASTM A325 grade) 72 pcs 0.99 71.45
6 Ordinary bolt M20 Grade: Class 4.8
(ASTM A307 grade) 36 pcs 0.62 22.15
7 Ordinary bolt M12 Grade: Class 4.8
(ASTM A307 grade)
200 pcs 0.20 39.69
Subtotal: US$1,325.37
Total Ex-Works price: US$35,912.47
F Transportation
1 Packing, container loading, container haulage from
LIBIDA factory to nearest seaport in China, Custom
declaration and port charge
in China 40'OT 1 ctns 992.37 992.37
2 40'HQ 1 ctns 992.37 992.37
3 20'GP 1 ctns 916.03 916.03
Subtotal: US$2,900.76 Total FOB Dalian port price: US$38,813.24
Floor area: 260m² Unit pirce: $149.28/m² H Payment method
30% deposit: US$11,643.97 Balance to be paid: US$27,169.27 PAYMENT TERM: 30% deposit before production, balance to be paid before shipment. VALIDITY OF THE QUOTATION: This quotation is valid within 7 days from the date of this quotation. DELIVERY TIME: Shipment will be made in 30 days after deposit payment has been received by Seller and construction drawing has been confirmed by Customer Notes: 1.This quotation doesn't include concrete ground foundation
2. Standard colors red, sea blue or off-white have no minimum order quantity requirement. 3. Other colors like green,5 High Strength bolt M20 Grade: Class 10.9S
(ASTM A325 grade) 72 pcs 0.99 71.45
6 Ordinary bolt M20 Grade: Class 4.8
(ASTM A307 grade) 36 pcs 0.62 22.15
7 Ordinary bolt M12 Grade: Class 4.8
(ASTM A307 grade)
200 pcs 0.20 39.69Ordinary bolt M12 Grade: Class 4.8
(ASTM A307 grade)
200 pcs 0.20 39.69
Subtotal: US$1,325.37
Total Ex-Works price: US$35,912.47
F Transportation
1 Packing, container loading, container haulage from
LIBIDA factory to nearest seaport in China, Custom
declaration and port charge
in China 40'OT 1 ctns 992.37 992.37
2 40'HQ 1 ctns 992.37 992.37
3 20'GP 1 ctns 916.03 916.03
Subtotal: US$2,900.76 Total FOB Dalian port price: US$38,813.24
Floor area: 260m² Unit pirce: $149.28/m² H Payment method
30% deposit: US$11,643.97Roof panel 1.0.5mm Single steel panel
(ASTM A755M) 2. Panel cover width: 840mm
3. Standard color: sea blue, off white ,red,dark grey 247 m
2 4.96 1223.84
If the area exceeds 600
square meters, other colors are available, and the price is negotiable 2 Roof insulation 100mm Rockwool sandwich panel. 247 m
2 7.34 1811.29
3 Wall panel 1.0.5mm Single steel panel
(ASTM A755M) 2. Panel cover width: 900mm
3. Standard color: sea blue, off white ,red,dark grey 324 m
2 4.56 1479.02
If the area exceeds 600
square meters, other colors are available, and the price is negotiable 4 Roof insulation 100mm Rockwool sandwich panel. 324 m
2 7.34 2379.29
5 Mezzanine decking sheet 1.0mm galvanized decking sheet 62 m
2 14.49 898.29 V 690
Including stud
Subtotal: US$7,791.73 C Door and window
1 Door 1 4880mm(W)*2740mm(H)*3 40.12 m2 119.08 4777.65 Electric lifting door 2 Door 2 900mm(W)*2100mm(H)*2 3.78 m
2 79.39 300.09 Steel plate security door 3 Window1
2000mm(W)*800mm(H)*8 （JG/T3018-94 equivalent to ASTM D4726）
12.8 m
2 69.47 889.16 PVC frame and tempered
glass window
Subtotal: US$5,966.90 D Accessorries 1 Self-drilling screw
55*5.5
( GB/T 15856.4-2002 equivalent to ASTM C1513-04) 2283 pcs 0.08 181.21
For roof and wall board
installation
2 Rivet nut 4*13
(GB12618 equivalent to ASTM
A502) 524 pcs 0.01 5.20 For bending part installation
3 Color steel accessories 0.5mm Single steel panel
(ASTM A755M) 131 m
2 6.35 832.00 Bending part 4
https://www.youtube.com/watch?v=JX1r-NGMwuc Client: William
Project name: Delivery Term: FOB Dalian port Dimension: 52-32-18ft project Contact Person: Caroline
Load Wind load:2.4kpa Snow load: 0.45kpa Container: 1*40OT+1*40'HQ+1*20'GP
Item Name Specification Qty Unit Ex-Works price (USD) Amount (USD) Remarks A Steel structure 1 Beam and column Welded H steel, material grade: Q355B (equivalent to S355JR, ASTM A572 Gr. 50)
13.579 Ton 936.79 12720.84
Price includes construction
drawing detailing, cutting, assembling, welding, straightening, shotblasting, derust Sa 2.5 grade and auti- rust painting
2
Stairs Checkered steel plate and square
tube handrail: material grade: Q235B (equivalent to S235JR, ASTM A36) 1.55 Ton 1532.21 2374.93
2 Roof tube brace Dia.89*3, material grade: Q235B
(equivalent to S235JR, ASTM A36) 0.365 Ton 916.95 334.72
3 Roof brace 20mm steel bar, material grade: Q235B (equivalent to S235JR, ASTM A36)
0.083 Ton 916.95 76.15
4 Column brace 20mm steel bar, material grade: Q235B (equivalent to S235JR, ASTM A36)
0.087 Ton 916.95 80.15
5 Purlin brace
L steel: L50*4.0, material grade: Q235B (equivalent to S235JR, ASTM A36)
0.038 Ton 916.95 34.59
Price includes fabrication and material is galvanized
6 Tie rod
12mm steel bar, material grade: Q235B (equivalent to S235JR, ASTM A36)
0.516 Ton 916.95 472.91
7 Casing Dia .32*2.5, material grade: Q235B
(equivalent to S235JR, ASTM A36) 0.233 Ton 916.95 213.71
8 Roof purlin C280X70X20X2.5 , material grade: Q355B (equivalent to
S355JR, ASTM A572 Gr. 50)
1.7 Ton 833.59 1446.98
9 Wall purlin C160X60X20X2.0 , material grade: Q355B (equivalent to S355JR, ASTM A572 Gr. 50)
3.7 Ton 833.59 3073.47
Subtotal: US$20,828.47 B Roof and wall
